Swimming Pool most efficient quietest underfloor heating air cooler air source heat pump
A new product called air-energy water heater has entered people's field of vision. This magical water heater can provide heat like traditional water heaters without electricity, gas, or solar energy. This kind of air-only water heater is actually designed and heated according to the "reverse Carnot" principle. To put it vividly, it is like an air conditioner in a reverse working state, that is, the "outdoor unit" is used to compress air like an air pump to increase the temperature of the air entering the water heater, and then pass through a type that will boil at -17°C. The liquid conducts heat to the indoor water storage tank, and then releases the heat to the water, so that the water heater continuously produces hot water.
Compared with other water heaters (gas water heaters, electric water heaters, solar water heaters), air energy water heaters have the following advantages:
(1) Energy saving. Based on the heat pump technology, the air energy water heater uses a small amount of electric energy to transfer the low-temperature heat energy in the air to the hot water to realize water heating. By obtaining a large amount of low-temperature heat energy in the air, its energy efficiency ratio is as high as 4.5.
(2) Security. The air-energy water heater adopts a water and electricity separation design during the heating process to avoid electric leakage and electric shock; there is no fuel delivery during the heating process, which can avoid the danger of fire and poisoning caused by fuel leakage.
(3) Environmental protection. The heating process of the air energy water heater is to use the working medium to realize energy conversion, and there is no waste discharge that pollutes the environment, thus achieving the effect of environmental protection.
(4) Convenient. The air-energy water heater is easy to install, whether it is outdoors or indoors, as long as there is installation space, the air heat can be obtained. At the same time, the air-energy water heater is less affected by the external environmental conditions, and can realize heating in winter and rainy days.
Four major parts of refrigeration: evaporator, compressor, condenser and throttling device. Three major parts of stability: liquid storage tank (compressor), expansion valve (capillary tube), filter drier (filtering moisture and impurities) A major defrosting part: the four-way valve realizes the traditional energy conversion theory and achieves fast results: the heat pump is in When working, the working fluid can absorb the energy QA stored in the ambient medium in the evaporator; and the starting system needs to consume energy, that is, the compressor power consumption QB; at the same time, the working fluid releases the heat QC of the high-temperature medium in the condenser; the compressor input After the work starts the system, it changes from mechanical kinetic energy to thermal energy. Therefore, the energy delivered by the heat pump is the sum of the work QB done by the compressor and the heat QA absorbed by the heat pump from the environment; input a QB to get QB+QA, which realizes the bottleneck of traditional single energy conversion and good efficiency; adopts heat pump technology Higher energy efficiency ratio
most efficient quietest underfloor heating air cooler air source heat pump specification
|Spec. ||KRY-8II ||KRY-12II ||KRY-24II ||KRY-48II ||KRY-96II ||KRY-145II ||KRY-220II |
|Rated heating capacity(A24/26oC) ||8kw ||12kw ||24kw ||48kw ||96kw ||145kw ||220kw |
|Rated power(kW) ||1.56 ||2.35 ||4.7 ||9.3 ||18.5 ||23.6 ||42.5 |
|COP ||5.1 ||5.1 ||5.1 ||5.16 ||5.41 ||6.14 ||5.17 |
|Rated heating capacityA20/26oC ||7.5kw ||11kw ||21kw ||44 kw ||90kw ||138kw ||208kw |
|Rated power(kW) ||1..5 ||2.3 ||4.5 ||8.6 ||17.5 ||24.1 ||41.5 |
|COP ||5 ||4.78 ||4.66 ||5.11 ||5.14 ||5.73 ||5 |
|Cooling Capacity(kW) ||3.8 ||5.7 ||11.3 ||23.7 ||40 ||58.1 ||98 |
|Consumed Power(kW) ||1.67 ||2.5 ||4.9 ||9.1 ||18.2 ||24.2 ||39 |
|EER ||2.3 ||2.3 ||2.3 ||2.6 ||2.2 ||2.4 ||2.5 |
|Rated voltage(Hz) ||220V 50HZ ||220V 50HZ ||380V 3N-50HZ ||380V 3N-50HZ ||380V 3N-50HZ ||380V 3N-50HZ ||380V 3N-50HZ |
|Maximum input power(kW) ||2 ||3 ||6 ||12 ||24 ||36.5 ||61 |
|Maximum current(A) ||8 ||12 ||24 ||42 ||80 ||90 ||130 |
|Water flownWh ||2.3 ||3.5 ||7 ||13 ||32 ||41 ||62 |
|noise dB(A) ||<50 ||<50 ||<65 ||<68 ||<69 ||<71 ||<73 |
|Anti-shock level ||I ||I ||I ||I ||I ||I ||I |
|waterproof level ||IPV4 ||IPV4 ||IPV4 ||IPV4 ||IPV4 ||IPV4 ||IPV4 |
|Unit size (mm) ||910x350x835 ||1030x410x865 ||780x820x1700 ||1550x780x1700 ||1550x1550x1700 ||2360x1550x1840 ||2206x2020x2170 |
|Unit Weight(kg) ||65 ||95 ||260 ||380 ||760 ||2100 ||4005 |
